Grazer SG

SG Surface Grazer Channel – the perfect lighting solution for both indoor and outdoor spaces that require a narrow or symmetric light distribtuion. With an impressive LED output ranging from 200 to 875 lumens per foot upto IP67, this channel offers a customizable brightness that suits any environment.

Available in silver, white, black, and custom colors . Whether you’re looking to enhance your commercial space or elevate your residential area, this LED Channel provides a sleek and modern touch.Illuminate your surroundings with style and precision, transforming any space into a captivating and well-lit environment.

spec sheet install instructions

TECHNICAL SPECIFICATION

Model	Lumen	Power	Length Increments	Color	Max Run Length	Dimming	Voltage	Rating	Distribution
P HP PH1 PH2 PH3 PH4 PH5 RGB RGBW Tunable White Tunable Warm White	200 lm/ft 300 lm/ft 405 lm/ft 600 lm/ft 875 lm/ft 1125 lm/ft 1463 lm/ft 126 lm/ft 213 lm/ft 242 lm/ft 253 lm/ft	1.3 w/ft 2.2 w/ft 3.0 w/ft 4.0 w/ft 6.1 w/ft 7.7 w/ft 10.5 w/ft 1.5 w/ft 2.4 w/ ft 4.4 w/ft 6.5 w.ft	4.92 in 3.93 in 2.46 in 1.96 in 1.31 in 1.64 in 1.23 in 3.94 in 3.94 in 3.28 in 3.28 in	19k-65k RGB RGBW(30k) 19-27k 27-60k	16 ft	Low Volt, 0-10V Low Volt, 0-10V Low Volt, 0-10V Low Volt, 0-10V Low Volt, 0-10V Low Volt, 0-10V DMX DMX DMX, 0-10V DMX, 0-10V	24v	IP20-IP67 IP20-IP67 IP20-IP67 IP20-IP67 IP20-IP67 IP20-IP40 IP20-IP40 IP20-IP67 IP20-IP67 IP20-IP67	120°

Model

Lumen

Power

Length Increments

Color

Max Run Length

Dimming

Voltage

Rating

Distribution

P
HP
PH1
PH2
PH3
PH4
PH5
RGB
RGBW
Tunable White
Tunable Warm White

200 lm/ft
300 lm/ft
405 lm/ft
600 lm/ft
875 lm/ft
1125 lm/ft
1463 lm/ft
126 lm/ft
213 lm/ft
242 lm/ft
253 lm/ft
